pdb-bg

Efficient

Powerful, instant, high-quality, simple, extraordinary. Enables rapid switching and meets emergency energy needs.

Reliable

Safe, secure, vibrant. Meets various outdoor, RV, travel, and other needs.

Smart

Cutting-edge technology, leading, trendy. Suitable for smart home scenarios.

Professional

Outstanding, skilled, interesting, confident. Meets professional work projects and proactively avoids risks.

-便携2

Product Specification

Model

GB2000(120Vac / 230Vac)

GB1500(120Vac / 230Vac)

Battery

Battery Type

Li(NiCoMn)O2

LiFePO4

Battery Capacity [Wh]

2016

1536

Battery Input Voltage [V]

48

51.2

Battery Input Voltage Range [V]

42~54.75

44.8~58.4

Rated Charge Current [A]

21

15

Maximum Charge Current [A]

42

30

Rated Discharge Current [A]

42

30

Maximum Discharge Current [A]

84

60

Cycle Life(@25°C, 0.5C charge and 0.5C discharge)

2000

2000

AC Input

Maximum AC Charging Power [W]

1800

2000

1500

Rated Voltage [Vac]

110/120

220/230

110/120

220/230

Voltage Range [V]

88~144

176~264

88~144

176~264

Rated Frequency [Hz]

60

50

60

50

Frequency Range [Hz]

47~63

Power Factor (at maximum charging power)

>0.99

AC Output

Number of AC Outputs

4

2

Rated Output Power [W]

2000

1800

Peak Power [W](@200mS)

4000

3600

Nominal Grid Voltage [Vac]

110/120

220/230

110/120

220/230

Nominal Grid Frequency [Hz]

60

50

60

50

Harmonic Distortion at Rated Power

<5%

<5%

DC Input

Maximum PV Charging Power [W]

600

600

PV Charging Voltage Range [V]

12~60

12~60

Maximum PV Charging Current [A]

10

10

DC Output

USB-A Fast Charging

4 x 18W Max (QC3.0, 5V/3A, 9V/2A, 12V/1.5A)

USB-C

2 x 140W Max (PD3.1, 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A, 28/5A)

5521

2 x37.8W Max (12.6V/3A)

2 x37.8W Max (12.6V/3A)

Car Charging

132W Max (13.2V/10A)

132W Max (13.2V/10A)

UPS Function

Transfer Time

≦12ms

≦12ms

Other Features

App Management

Wi-Fi and Bluetooth

Battery Expansion

Yes

Display

LCD

Ambient Light

Yes

Protection Functions

Protection

AC Output Overcurrent; AC Output Short Circuit; AC Charging Overcurrent;

AC Output Over/Under Voltage; AC Output Over/Under Frequency; Inverter Overtemperature;

AC Charging Over/Under Voltage; Battery High/Low Temperature; Battery Over/Under Voltage;

General Data

Cooling Method

Fan Cooling

Operating Temperature Range [°C]

Operating Temperature Range [°C]: 0 to 50 (charging), -10 to 60 (discharging)

Operating Relative Humidity [RH(%)]

Operating Relative Humidity [RH(%)] Range: 0-95, non-condensing

Protection Level

IP20

Noise Level [dB]

<55dB

Weight (kg)

20.65

18.35

Product Dimensions (mm)

365*210*281

Package Dimensions (mm)

525*332*363
